ECTRAY cable trunking delivers reliable cable protection through a fully enclosed design. Manufactured from premium materials with precision engineering, it offers excellent mechanical strength, corrosion resistance, and easy installation, making it an ideal solution for industrial facilities, commercial buildings, infrastructure, and data centers.
The enclosed design provides complete coverage around installed cables, protecting them from mechanical impact, dust accumulation, moisture, and environmental exposure.
Manufactured using high-quality metal materials, ECTRAY cable trunking provides strong structural stability and reliable load-bearing capability.
ECTRAY cable trunking is available in various material options, including galvanized steel, stainless steel, and aluminum alloy, allowing customers to select the most suitable solution according to environmental conditions, corrosion requirements, and project specifications.
The modular structure simplifies installation by allowing easy connection, adjustment, and system expansion.
ECTRAY cable trunking is designed to accommodate different cable types, including power cables, control cables, and data communication cables.
Hot-dip galvanized cable trunking is manufactured by applying a protective zinc coating to steel through a high-temperature galvanizing process.
Manufactured from 304 or 316 stainless steel, it offers excellent resistance against oxidation, chemicals, and high humidity, ensuring reliable cable protection in harsh operating conditions.
Powder coated cable trunking features an additional protective coating applied through an electrostatic powder coating process.
Model | Height(mm) | Width(mm) | Length(mm) |
CT-100-100 | 100 | 100 | 3000/4000/6000 |
CT-100-200 | 100 | 200 | 3000/4000/6000 |
CT-100-300 | 100 | 300 | 3000/4000/6000 |
CT-100-400 | 100 | 400 | 3000/4000/6000 |
CT-100-500 | 100 | 500 | 3000/4000/6000 |
CT-100-600 | 100 | 600 | 3000/4000/6000 |
CT-150-100 | 150 | 100 | 3000/4000/6000 |
CT-150-200 | 150 | 200 | 3000/4000/6000 |
CT-150-300 | 150 | 300 | 3000/4000/6000 |
CT-150-400 | 150 | 400 | 3000/4000/6000 |
CT-150-500 | 150 | 500 | 3000/4000/6000 |
CT-150-600 | 150 | 600 | 3000/4000/6000 |
CT-200-100 | 200 | 100 | 3000/4000/6000 |
CT-200-200 | 200 | 200 | 3000/4000/6000 |
CT-200-300 | 200 | 300 | 3000/4000/6000 |
CT-200-400 | 200 | 400 | 3000/4000/6000 |
CT-200-500 | 200 | 500 | 3000/4000/6000 |
CT-200-600 | 200 | 600 | 3000/4000/6000 |
Environment | Recommended Material | Typical Applications | Key Benefits |
Office Buildings | GI Steel | Office wiring systems, commercial interiors | Clean appearance and economical cable protection |
Commercial Facilities | Powder-Coated Steel | Hotels, shopping malls, educational buildings | Improved aesthetics with additional surface protection |
Electrical Rooms | GI Steel | Switch rooms, control rooms, distribution rooms | Organized cable routing and easy maintenance |
Industrial Workshops | HDG Steel | Production workshops, machinery areas | Enhanced durability in demanding environments |
Chemical Processing Areas | Stainless Steel | Chemical factories, pharmaceutical plants | Reliable protection against corrosion and chemicals |
